Did you find a bicycle at a garage sale or on craigslist but don’t know its size? We’ll show you how to measure a bicycle frame to determine its size.

Bicycles are sold by frame height, and that is the primary measurement that determines if a bike fits the rider or not. The main purpose of this article is to show how to measure a bike frame. If you need to find out if a particular bicycle frame fits you, see my article about road bike sizing.

How to Measure a Bicycle Frame

Frame size is measured from the center of the bottom bracket at the crank spindle to the top of the seat tube where the seat post enters the frame.
Hold the end of your tape measure at the center of the bottom bracket spindle and measure to the top of the seat tube.

How to measure a bicycle frame - starting from the center of the crank spindle.
Hold the end of your tape measure at the center of the bottom bracket spindle
Measure to the top of the seat tube.
Measure to the top of the seat tube

Use the table below if you need to convert your measurement from inches to centimeters or from centimeters to inches.

Frame Size
InchesCentimeters
16.040.6
16.541.9
17.043.2
17.544.5
18.045.7
18.547.0
19.048.3
19.549.5
20.050.8
20.552.1
21.053.3
21.554.6
22.055.9
22.557.2
23.058.4
23.559.7
24.061.0
24.562.2
25.063.5
25.564.8
26.066.0
26.567.3
27.068.6
27.569.9
28.071.1

That’s all there is to measuring a bicycle frame to determine its size. There are other frame measurements, but frame height is the most important measurement as far as frame fit for a particular rider is concerned.

Amazon and the Amazon logo are trademarks of Amazon.com, Inc, or its affiliates.

About Greg Dickerson

I got my first 10-speed bike at the age of 14 and have been addicted to cycling ever since. Living in the Pacific Northwest, I've ridden the Seattle to Portland (STP) and Providence Bridge Pedal rides several times.  Due to having a traveling job, I've had the opportunity to ride in several states when away from home as well.

View all posts by Greg Dickerson →

2 Comments on “How to Measure a Bicycle Frame”

  1. The initial diagram is misleading. It`s showing the distance A as vertical instead of along the length of the tube. The two will be different. I assume from the pictures that you measure along the tube not the vertical height from the crank to the top of the tube?

    1. You are correct. The measurement is taken along the length of the tube. The two photos in the article show illustrate how to measure a bicycle frame better than the diagram at the top of the article does.
